DIY Outdoor Kitchen Diagonal Corner Module with Sink/Countertop Support Kit BAR HEIGHT

No reviews yet Write a Review
Ask Questions

DIY Outdoor Kitchen Diagonal Corner Module with Sink/Countertop Support Kit BAR HEIGHT

$399.99
$749.99
MSRP $749.99
On Sale
(You save $350.00 (47%))
  • SKU: BBQ-DCMOD-BH
In Stock & Ready To Ship!
Current Stock:Only left:
Description

DIY Outdoor Kitchen Diagonal Corner Module with Sink/Countertop Support Kit

BAR HEIGHT 41"

Reg Price $749.99 SALE $399.99

Free Shipping on Orders Over $400 (In the continental USA)

IN STOCK! (Ships in 3-7 Business Days)

This is a big module and is best for large patios only.

video shows standard height vertical tubes but with this item you will receive longer bar height vertical tubes

This is our famous 31 1/2" Diagonal Corner module (Bar Height) used for large L or U Island Designs.

This is a big module and is best for large patios only.

The front diagonal is approx 18 3/4" and best fits a 14x20 vertical door to access plumbing for sink or egg soot opening.

MEASUREMENTS

45 3/4 x 45 3/4" on the 2 rear sides

31 1/2" one the 2 ends where straight modules will connect

41" Height



Includes:

4ea Length Tubes 43 3/4" x 25mm (Red paint)

4ea Length Tubes 30 3/4" x 25mm (Red paint)

2ea 21mm Diagonal Front Tubes

9ea Bar Height Vertical Tubes (Black paint) (2 of these BH VTs are for a door at the angle)

6ea 3 way corner couplers

10ea One Way Couplers (Standard with both wings)

4ea One Way Couplers (For tight spaces with one wing)

Sink / Countertop Kit for Outdoor Kitchen Diagonal Corner Module

2ea 45 Degree Couplers

6ea one way couplers

2ea 4ft x 25mm tubes

2 each CTT

Not Included: Actual outdoor kitchen appliances, cement board, screws, vents, leveling feet , etc...

It does not include the egg smoker platform to support an outdoor kitchen smoker. (sold separate)
